Entire electromagnetic spectrum
Wavelength[m]
3*107
3*105 3*103   30 3 0,3     3*10-4     3*10-8       3*10-12     3*10-15
Frequency[Hz] 0 101 102 103 104 105 106 107 108 109 1010 1011 1012 1013 1014 1015 1016 1017 1018 1019 1020 1021 1022 1023


  techn. AC

  telephone

  long waves

  medium waves

  short wave SW
  VHF

  microwaves

infrared IR

  visible spectrum

  ultraviolet UV

  X - rayes

  gamma radiation

  cosmic-ray
  radiation

Wavelength[m]   3*107 3*105 3*103   30 3 0,3   3*10-4     3*10-8   3*10-12   3*10-15
Frequency[Hz] 0 101 102 103 104 105 106 107 108 109 1010 1011 1012 1013 1014 1015 1016 1017 1018 1019 1020 1021 1022 1023
long waves:30 km to 600 m micro waves: : 1m to 0,1 mm infrared IR: 1,4 mm to 0,75 m X rays: 60 nm to 10-5 nm
medium waves:600 to 200 m visible light: 0,78 to 0,4 m gamma radiation: 10-11 to 10-16 m
short waves:200 to 10 m ultraviolet UV: 400 nm to 3 nm
VHF: 10 to 1 m
